The Champion of Champions !

TOC Champion, IMAC World Champion,

Tucson Aerobatic Shootout Champion, IMAC National Champion

Incomparable throttle transition

Incredible power

Extremely low vibration

Standard and Light (Special machined cylinders) versions available

All engines come with ignition, prop washer, and prop bolts.

***Engines will no longer come with a paper manual, but instead a QR code linking you to the manual.  This will allow you to be able to pull up your manual on any electronic device.  If you need a paper manual, please include that in your notes for your order.

Click here for parts

Click here for 3 Views

Instruction Manual

Baffling Template

Specifications

• Displacement: 12.20 ci (200 cc)
• Output: 19 hp
• Weight: Standard:10.95 lbs (4.95 kilos)   Light: 10.05 lbs. (4.56 kilos)
• Bore: 1.6771 in (42.6 mm)
• Stroke: 1.3779 in (35 mm)
• Length: 9.625 in (244 mm)
• RPM Range: 900 - 6,700
• RPM Max: 8,500
• Fuel Consumption: 4.5 oz/min @ 6,000 RPM
• Warranty: Two years
• Bolt Circle: 34mm
• Prop Bolt: (6) 5mm

Features

• Four petal reed valve, bottom induction.
• Desert Aircraft, auto advance, electronic ignition system.
• Walbro Carburators
• Crankshaft designed, manufactured, and assembled to aerospace standards at our Tucson Arizona factory.
• Exclusive Desert Aircraft designed cylinders and pistons.
• CNC milled, 7075 aluminum alloy crankcase.
• Low vibration.
• Long rod to stroke ratio.
• Aerobatic power curve.
• DA engines are designed using the latest tools and techniques, including 3D CAD and Stereo Lithography.
• Extremely low vibration.

Recommended Props

2-Blades

• 30x13
• 31x12
• 32x10
• 32x11
• 32x12

3-Blades

• 29x12
• 29x12n
• 29x12evo (Best)
• 29x13
